Technical details
LSZH – low smoke zero halogen
UV-resistant
Longitudinaly and laterally water-resistant
Glass yarn armoured
Non-metal rodent protection
Metal free
Core diameter : 50.0 ± 2.5 µm
Cladding diameter : 124.8 ± 1.0 µm
Core-non-circularity : ≤ 5.0 %
Cladding-non-circularity : ≤ 1.0 %
Core-cladding concentricity error : ≤ 1.0 µm
Coating diameter : 245 ± 7 µm
Coating non-circularity : ≤ 6.0 %
OFL bandwidth : at 850nm : ≥ 3500 MHz x km ; at 1300nm : ≥ 500 MHz x km
Effective modal bandwidth : at 850 nm : ≥ 4700 MHz x km ; at 1300nm : ≥ 500 MHz x km
Fiber count (OM4) : 2-12 pc
Max. number of loose tube : 1 pc
Fiber number per tube : 2 - 12 pc
Loose tube : 2.0 ± 0.2 mm
Outher sheath material : LSZH, CPR Dca, EN 50575: 2014+A1: 2016
Cable outer diameter : 6.5 ± 0.5 mm
Max. allowable pulling force : 1400 N
Crush resistance : 1000/200 N/100mm
Temperature range : transport and storage : - 40°C to + 70°C ; installation : - 40°C to + 60°C ; operation : - 40°C to + 70°C
Min. bending radius : installation : 20 x OD ; operation : 10 x OD
Temperature range : transport and storage : - 40°C to + 70°C ; installation : - 40°C to + 60°C ; operation : - 40°C to + 70°C
Application: Inside/outside
Armouring: no
Blow in: no
Cable metal free: yes
Colour outer sheath: Turquoise
Fibre category: OM3
Fibre type: Multi mode 50/125
Halogen free (acc. EN 60754-1/2): yes
Longitudinal water blocking: yes
Low smoke (acc. EN 61034-2): no
Material outer sheath: PE (polyethylene)
Number of fibres: 4
Oil resistant (acc. EN 60811-404): no
Radial water blocking: yes
Resistant to chemicals: no
Strain relief: yes
Type of tube: Loose tube
With rodent protection: no
